SPECIFICATIONS |
YD-350RX |
YD-400RX |
|
|
Control model |
|
IGBT |
|
|
Rated input voltage |
V |
AC 380 |
AC 415 |
|
Rated input |
KVA/KW |
13.2/12.7 |
16.2/15.6 |
|
Rated output current |
A |
DC 350 |
DC 400 |
|
Rated output voltage |
V |
31.5 |
34 |
|
Rated duty cycle |
% |
60 |
|
|
Output voltage range |
V |
16.5 – 35.5 DC |
|
|
Output current range |
A |
50 – 430 |
|
|
Wave form control method |
|
Digital control |
|
|
Welding control |
|
CO2/MAG |
|
|
Dimension |
mm |
545x380x570 |
|
|
Mass |
kg |
52 |
|
